Single-stage incubation equipment

Single-stage incubators represent the pinnacle of poultry egg incubation technology. These high-performance incubators boast substantial capacity and facilitate comprehensive hatching processes, drawing upon empirical data and the results of rigorous research and development. Their primary objective is to yield superior quality chicks while delivering professional-grade services.

Features

• High capacity options: 40320, 60480, 120960;
• The whole batch in and whole batch out technique provides uniform day-old chicks and good epidemic prevention performance;
• Uniform temperature field: distributed heating/cooling modules + section control;
• Uniform airflow field: laminar airflow + even air design;
• Little effect of humidifying and fresh air, long space for humidifying and fresh air mixing.

Specs

• Power 5.9 KW to 27.6KW
• Temp control range 20℃ ～ 38.5℃
• Humidity control range 40%～70%RH
• Stability of temperature field ≤0.10℃
• Egg turnover angle 42°±2°
• Chick series 40320/60480/120960
• Duck series 34560/69120
•  60480 series: 12 Egg trolleys + 15 Egg trays + totally 40320 setters
•  120960 series: 24 Egg trolleys + 15 Egg trays + totally 40320 setters
